One function per spatial command, each a thin wrapper: the command name,
the options it takes and the table TDA writes. They all work on a
tda_spatial structure, however it was built – from a data
frame with tda_spatial, from a shapefile with
tda_read_shapefile, or from line segments with
tda_polygons.
Usage
tda_sd_info(s, ...)
tda_sd_relations(s, ...)
tda_sd_neighbours(s, ...)
tda_sd_enclosing(s, shape = c("rectangle", "hull"), ...)
tda_sd_voronoi(s, ...)
tda_sd_select(s, ...)
tda_sd_intersect(s, ...)
tda_sd_lines(s, ...)
tda_sd_points(s, ...)
tda_sd_data(s, ...)
tda_sd_clip(s, rec, ...)Arguments
- s
a
tda_spatial.- ...
options for the command.
- shape
for
tda_sd_enclosing,"rectangle"(default) or"hull"(the convex hull);sdencl'sopt=.- rec
the clipping rectangle,
xmin,ymin,xmax,ymax.
Details
tda_sd_info reports what a structure holds: how many points, lines
and polygons, and the bounding box. tda_sd_voronoi builds a
Voronoi diagram and the Delaunay triangulation of the points;
tda_sd_enclosing the enclosing rectangle or the convex hull,
tda_sd_neighbours nearest-neighbour lists, and
tda_sd_relations the relations between objects.
tda_sd_select picks out objects in a region – like
tda_sd_clip, it needs rec (as an option:
tda_sd_select(s, rec = "0,0,1,1")), which TDA will not guess. The
polygon operations – tda_sd_intersect, tda_sd_lines,
tda_sd_points and tda_sd_clip – each write a record file
that comes back as a table.
See also
Other spatial analysis:
plot.tda_spatial(),
tda_map(),
tda_polygons(),
tda_read_dbf(),
tda_read_shapefile(),
tda_read_spatial,
tda_sd(),
tda_sd_ps3(),
tda_spatial()
Examples
# four points, as a spatial structure
d <- data.frame(id = 1:4, x = c(0, 1, 1, 0), y = c(0, 0, 1, 1))
s <- tda_spatial(d)
# what is in it
tda_sd_info(s)
#> Call: tda_sd_info(s)
#>
#> Cases: 4
#>
#> points lines polygons xmin ymin xmax ymax
#> 4 0 0 0 0 1 1
# the Voronoi diagram of those points: what sdvd writes is itself a
# spatial data file (points for the Voronoi vertices, lines for the
# edges), so plot() reads it back with the input's plot machinery
v <- tda_sd_voronoi(s, opt = 2)
plot(v, xlim = c(-0.5, 1.5), ylim = c(-0.5, 1.5))
# clip to a rectangle; rec is required, TDA will not guess one
tda_sd_clip(s, c(0, 0, 0.5, 0.5))
#> Call: tda_sd_clip(s, c(0, 0, 0.5, 0.5))
#>
#> Cases: 4
#>
#> 2 records, lengths 2-5
#> [1] 1 1 1 1 1
#> [2] 0 0
# a select needs one too, the region to select within
tda_sd_select(s, rec = "0,0,1,1")$table
#> 8 records, lengths 2-5
#> [1] 1 1 1 1 1
#> [2] 0 0
#> [3] 2 1 1 2 1
#> [4] 1 0
#> [5] 3 1 1 3 1
#> [6] 1 1
#> [7] 4 1 1 4 1
#> [8] 0 1
# relations and nearest neighbours, on the same points
tda_sd_relations(s)
#> Call: tda_sd_relations(s)
#>
#> Cases: 4
#>
#> Elementary topological relations. Current memory: 406449 bytes.
#> 0 records written to: out.txt
tda_sd_neighbours(s)
#> Call: tda_sd_neighbours(s)
#>
#> Cases: 4
#>
#> Creating a network from lines. Current memory: 406449 bytes.
#> Number of lines: 0
#> Number of segments: 0
#> Tolerance: 0.0001
#> Maximal number of segments: 0
#> Number of nodes: 0
#> Number of edges: 0
#> 0 records written to: out.txt
tda_sd_enclosing(s, shape = "hull")$table
#> 5 records, lengths 1-2
#> [1] 4
#> [2] 0 1
#> [3] 0 0
#> [4] 1 0
#> [5] 1 1
# polygon data: typ = 3 groups consecutive rows sharing an id into one
# polygon each -- here two squares
poly <- data.frame(id = c(1, 1, 1, 1, 2, 2, 2, 2),
x = c(0, 2, 2, 0, 3, 5, 5, 3),
y = c(0, 0, 2, 2, 0, 0, 2, 2))
sp <- tda_spatial(poly, type = 3)
tda_sd_data(sp)$table # the polygons' own vertex coordinates back out
#> V1 V2 V3
#> 1 1 0 0
#> 2 1 2 0
#> 3 1 2 2
#> 4 1 0 2
#> 5 2 3 0
#> 6 2 5 0
#> 7 2 5 2
#> 8 2 3 2
# tda_sd_intersect/tda_sd_lines/tda_sd_points compare polygons against a
# *different* object type (points or lines) already in the same spatial
# structure -- with only the two polygons above and nothing else, there
# is nothing for them to find, which is what they correctly report
tda_sd_lines(sp)$table
#> NULL
tda_sd_intersect(sp)$table
#> V1 V2 V3
#> 1 1 1 -1
#> 2 2 2 -1
tda_sd_points(sp)$table
#> NULL
# a real shapefile, if one is available: sf's example data, North
# Carolina counties -- everything above works on synthetic points or two
# squares; this is what these look like on real, complicated polygons
if (requireNamespace("sf", quietly = TRUE)) {
nc <- tda_read_shapefile(system.file("shape/nc.shp", package = "sf"))
print(tda_sd_info(nc)) # 108 counties, 2421 vertices
# relations' real answer is printed, not written to a file -- $text
# holds the boundary comparisons TDA's console output shows
head(tda_sd_relations(nc)$text, 4)
# a neighbour network needs line data; a set of polygons alone
# legitimately has none to report -- 0 nodes, 0 edges, not a bug
tda_sd_neighbours(nc)$text
tda_sd_enclosing(nc)$table # the whole state's bounding box
# select/clip write one record per vertex, not all the same length --
# a polygon's header row, then that many coordinate pairs, the
# same ragged shape as sdvd's edge list above -- a proper rectangular
# table is what tda_sd_data() gives instead
tda_sd_select(nc, rec = "-79,35,-77,36")$table # counties in a region
tda_sd_clip(nc, c(-79, 35, -77, 36))$table # the same, cut to it
head(tda_sd_data(nc)$table) # every county's vertices,
# as an ordinary data frame
}
#> Call: tda_sd_info(nc)
#>
#> Cases: 108
#>
#> points lines polygons xmin ymin xmax ymax
#> 0 0 108 -84.32385 33.88199 -75.45698 36.58965
#> V1 V2 V3
#> 1 1 -81.47276 36.23436
#> 2 1 -81.54084 36.27251
#> 3 1 -81.56198 36.27359
#> 4 1 -81.63306 36.34069
#> 5 1 -81.74107 36.39178
#> 6 1 -81.69828 36.47178
